Surgical Zoom Handpiece

*Minimum spot
*High efficiency transmission
For contactless applications:
Spider Vein / Nail fungus / Vascular Dermatosis

LVR therapy handpiece

Fiber diameter: 600um
Outside diameter: 35mm
Inside diameter: 24mm
Standard SMA905 connector Suitable for vaginal rejuvenation, Colposcopy Applications, HPV lesions, Cysts of the mucosa, Cervical intraepithelial neoplasia, etc.

ENT Handpiece

Include 7 pieces cannula Suitable for 400um fiber Offering you a wide choice of materials, designs and sizes to perform any ENT procedure with precision and speed.

Lipolysis Handpiece

Include 5 pieces cannula Suitable for 600um fiber It is possible to use different cannulas depending on the area, which is going to be treated.

Bare Fiber Handpiece

It can match with the mainstream laser machine all over the world. Any surgical laser machine of pluggable fiber, SMA905 or FC connector are all compatible

Bare Fiber

Silica fiber has excellent high temperature resistance and optical transmission properties for wide clinical applications
- Fiber tensile strength no less than 4.9N.
- Minimum bending radius 200d (d as fiber diameter)
- After tensile strength experiment, fiber emission efficiency no less than 90% as before.
Suitable for general surgery, different sizes are available according to the actual situation.

Radial Fiber

Connector: standard SMA 905
Fiber diameter: 400/730um, 600/750um
Glass OD: 1.2mm
Glass length: 10mm
Transmittance: >90%
ETO sterilization, double packing
360° radiation and optimized handling, standard for endovenous laser therapy

Holmium Fiber

Standard SMA/FC connector
Core[μm]: 272; 365; 550
Flat/air gap connector available
Extension sleeve available in various colors
Standard length 3m, NA=0.22/0.37
Specifically for use with most holmium and Nd:YAG laser systems on the market. Designed for durability,flexibility and versatility in urological procedures.

Focusing Handpiece

Fiber 300um, 400um
SMA905 connector
Magnification confocal: 1:1
Spot diameter: 1mm, 2mm and 3mm
For non-contact treatment:
Spider Vein
Nail fungus
Vascular Dermatosis

Side Fiber

Core[μm]: 600
Fiber tip: oblique 8 degrees
High power F-SMA905 connector
Extension sleeve available in various colors
Self-design on request
Apply to infrared (IR)
Standard length 3m
Provide a lateral light aimed directly at the prostate tissue, avoiding the sphincter, be used with a holder to perform rotations, telescoping and other surgical operations.
